Dear customer .Welcome to Snail Medical.
The laser uses a dual-wavelength laser platform that combines a 755nm Alexandrite laser fast, efficient, safe and powerful laser.
1. We are exclusive 755nm alexandrite laser manufacturer .
2. We can provide different 755nm machine model as below picture .
3. We sell whole 755nm alexandrite laser machine and also sell whole machine spare parts to foreign countries .
4. Our 755 alexandrite laser machine is targeting Korean 755 technology , Absolutely high-level configuration with reasonable price
5. Fast delivery after payment in 5 to 7 days
6. Support 755nm Alexandrite laser technology export and support build factory in local market
4.Details of Handpiece
The Headpiece is well designed, and the laser spotsizes can be adjusted from 8-16mm diameter, and a continuely headpiece cooling can cool the skin to get down skin tempreture, all that will enables the treatment much more convinent, comfortable and efficient.
Based on our strong R&D and design capabilities, as well as sufficient supply capacity, our company can also provide OEM/ODM services. If you have sufficient strength to become our partner or want to distribute our equipment locally, we will be committed to working with you.
| Items | Details |
| Monitor | 10 inches Digital Real Color LCD |
| Interface | Touch |
| Control system | Single chip |
| Headpiece/spot-size | Headpiece with slider, lens cap=6,8,10mm, lens cap=12,15,18mm |
| Large Spot-size | 20,22,24mm (optional) |
| Fiber with slider | My by Thorlabs US, 1.6mm diameter with 2600mm length |
| Protect window | Sapphire window |
| Distance Gauge | 18mm, 24mm(optional) |
| Canisters amount | One Dozen (12 bottles), US Type |
| Canisters Charge | Pre-charged or Pre-vacuumed |
| Canisters color | Yellow, Green, Blue, or Black |
| Cryogenic amount | 1 Kg |
| Cryogenic shots | About 20,000 shots |
| Valve | Fixed inside headpiece, US Type |
| DCD heat up | Auto control |
| DCD pressure | Auto control |
| DCD pulse duration | 10-60ms |
| DCD Pulse interval | 10-60ms |
| Cali port | Inside chamber and headpiece holder |
| Cali degree | By each parameter |
| Cooling system | Water circulation |
| Water temperature | 5-25 oC auto control |
| Water tank | US type |
| Filter | PP+DI filter |
| Heat radiator | Korea type, two pieces with 2000 watts each |
| Cooling Fan | 3000-6000 R/minute, speed auto control, 4 pices |
| Wavelength | 755nm |
| Energy | 60J@755nm |
| Lamps amount | One Pair |
| Lamps origin | Made by Heraeus UK |
| Lamps size | 10x162mm 770 ppi |
| Alexandrite Rod | 9.53x116mm US Type |
| ND YAG Rod | 9.53x116mm US Type |
| Pulse frequency | 0.5hz, 1Hz,1.5hz,2Hz,5.0hz, 10hz |
| Pilot beam | 520nm green laser |
| LBO | PP-LN |
| Power supply part | 3680 watts |
| IGBT part | Made by Infineon Germany |
| IGBT amount | Two |
| Capacitance capacity | 12500+40000uf=52500uf |
| In charge voltage | 750-1400V DC |
| Voltage input | 220V AC |
| Labels | Guide use and safety notice |
| Net weight | 70KG |
